IMI Delivers Record-Sized Choke Valves

IMI Achieves Milestone with World’s Largest Production Choke Valves for North Sea Platform

September 18, 2025

Record-Breaking Valve Delivery

IMI has completed delivery of unprecedented choke valves to a North Sea platform. These represent the largest production choke valves ever manufactured. The unmanned processing platform marks a significant industry advancement.

Engineering Specifications

The 100D DRAG multi-stage control valves measure 20×20 inches. They carry an ASME 4500 rating with 686 barg design pressure. Forged ASTM A182 F22 Cl materials form the valve body and bonnet. Additionally, Inconel 625 weld overlay provides superior corrosion resistance.

Advanced Technology Implementation

IMI’s patented DRAG technology incorporates solid tungsten carbide trim. This ensures exceptional durability under extreme conditions. Therefore, the valves withstand highly erosive, high-pressure environments effectively.

Quality Assurance Process

All three 100D DRAG valves passed rigorous factory acceptance testing. The Austrian production facility verified every performance parameter. Consequently, the equipment meets the highest quality standards.

Expert Commentary

Ronald Simon, IMI Principal Engineer for Oil & Gas, emphasized the achievement. He stated these valves demonstrate IMI’s flow control leadership. Moreover, they enable reliable operation in challenging unmanned environments.

Industry Significance

This delivery represents a major engineering accomplishment. Unmanned platforms demand exceptional equipment reliability. IMI’s valves ensure safe, efficient production in remote locations.

Technical Innovation Impact

The 100D DRAG valves incorporate multiple advanced features. Multi-stage, multi-turn design enables precise flow control. Furthermore, specialized materials guarantee long service life.

Future Implications

This project sets new standards for offshore flow control technology. It demonstrates IMI’s capability to handle extreme applications. The industry can expect further innovations following this success.

Operational Advantages

Unmanned platforms benefit significantly from this technology. Reduced maintenance requirements lower operational costs. Enhanced reliability ensures continuous production capability.

Application Scenario: Offshore Production

An unmanned North Sea platform requires maximum reliability with minimal intervention. IMI’s 100D DRAG valves provide precise flow control under extreme pressure. The platform operates safely and efficiently despite harsh conditions.

Frequently Asked Questions

What makes these choke valves unique?

They represent the largest production choke valves ever manufactured. Their size and pressure rating set new industry standards.

Why are these valves important for unmanned platforms?

They provide extreme reliability with minimal maintenance needs. This ensures continuous operation in remote locations.

What materials provide corrosion resistance?

Internal Inconel 625 weld overlay protects against corrosive elements. This extends valve lifespan significantly.

How were the valves tested?

They underwent comprehensive factory acceptance testing. IMI verified all performance parameters before delivery.

What applications suit these valves?

They excel in high-pressure, high-flow offshore environments. Particularly unmanned platforms demanding maximum reliability.
