22F-D6P0N113 – Allen-Bradley AC Drives

Description

Allen-Bradley 22F-D6P0N113 PowerFlex 4M AC Drive

Technical Specifications

Input Voltage: 380-480 V AC, 3-Phase

Output Voltage: 0-460 V AC, 3-Phase

Output Power: 2.2 kW / 3 HP

Output Current: 6 A

Control: Volts per Hertz (V/Hz) with IR and slip compensation

Enclosure: Open, IP20 / NEMA UL Type

Frame: B

Human Interface Module: Fixed keypad with LCD display

I/O: 5 digital inputs, 2 Form C relay outputs, 2 analog inputs (0-10 VDC, 4-20 mA)

Built-in EMC filter

Communication: RS485 built-in; supports DSI protocol

Mounting: Panel mount or DIN rail, supports Zero stacking

Ambient Temp: -10°C to 40°C / 14°F to 104°F

Frequency: 50-60 Hz

Dimensions: 3.94 x 6.85 x 5.35 in

Weight: 4.6 lbs / 2.1 kg

Download PDF file here:PowerFlex 4M Adjustable Frequency AC Drives
