3300 NSv Armored Probe – Bently Nevada – 330902-00-15-05-02-00

Description

Product Model: 330902-00-15-05-02-00

The 330902-00-15-05-02-00 is a small Bently Nevada 3300 NSv Proximity Probe. It checks shaft vibration and position. It works well in tight and hot spaces.

Key Details:

• Thread Type: 1/4-28 UNF, with armor
• Unthreaded Length: 0.0 inch (Code 00)
• Case Length: 1.5 inches (Code 15)
• Cable Length: 0.5 meter (20 inches, Code 05)
• Connector Type: ClickLoc miniature coaxial (Code 02)
• Agency Approval: Not required (Code 00)

Material:

• Case: AISI 304 stainless steel
• Tip: PPS (Polyphenylene Sulfide)
• Cable: 75 Ω coaxial, FEP insulated
• Other Cable Options: 1, 5, or 7 meters

Performance:

• DC Resistance: 4.0 ± 0.5 Ω (for 0.5 meter)
• Weight: About 14–150 g (0.5 to 5.3 oz)
• Operating Temp: -52°C to +177°C
• Storage Temp: -52°C to +177°C
• Seal: Viton O-ring (not pressure-tested)

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
