3300 NSv Armored Probe – Bently Nevada – 330909-00-99-10-02-00

Description

Product Model: 330909-00-99-10-02-00

Product Type: 3300 NSv Proximity Probe

The 330909-00-99-10-02-00 is a long-case vibration probe made in the U.S.A.. It is built to measure machine vibrations in tight or hard-to-reach places. This model is part of Bently Nevada’s reliable 3300 NSv series.

Model Details:
00 – No unthreaded length
99 – 9.9-inch case length
10 – 1.0-meter cable (39 in)
02 – Mini ClickLoc connector, standard cable
00 – No agency approvals required

Materials:
Case: AISI304 stainless steel
Tip: Polyphenylene sulfide (PPS)

Cable:
75-ohm coaxial with FEP insulation
Cable length: 1.0 meter

Electrical Resistance:
At 5.0 meters: 5.3 ± 0.7 ohms

Thread and Torque:
Thread type: 3/8-24 UNF
Max thread depth: 0.563 in
Max torque: 33.9 N·m (300 in·lb)
Recommended torque: 11.3 N·m (100 in·lb)

Temperature Range:
Operating: -52°C to +177°C (-62°F to +351°F)
Storage: -52°C to +177°C
Avoid long exposure below -34°C (-30°F) to protect the seal.

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
