3300 NSv Extension Cable | Bently Nevada 330930-040-01-CN

Description

330930-040-01-CN Key Specifications

Length: 4.0 m (13.1 ft)
Armor & Jacket: Option 01 = Flexible AISI 302 SST with FEP outer jacket
Approvals: CN = Country‑specific (download Quick Reference Guide & Field Notification)
Temperature: –51 °C to +177 °C (–60 °F to +351 °F)
Weight: 1.5 kg shipping weight

Electrical & Mechanical Details

DC Resistance: Center 0.220 Ω/m (0.067 Ω/ft); Shield 0.066 Ω/m (0.020 Ω/ft)
Capacitance: 69.9 pF/m (21.3 pF/ft) typical
Impedance Tolerance: ± 2 % nominal
Dielectric Strength: 1 500 Vrms for 60 s
Attenuation: ≤ 0.05 dB/m at 100 kHz

Jacket Thickness: 0.8 mm nominal
Shield Coverage: 90 % foil + braid
Flame Rating: UL 94 V‑0 certified
Compressive Strength: 500 N along cable axis

Field Wiring & Performance

Conductor Sizes: 0.2–1.5 mm² (16–24 AWG); with ferrules 0.25–0.75 mm² (18–23 AWG)
Max Run: 305 m (1 000 ft) to monitor
EMI Reduction: ≥ 20 dB at 1 MHz with triad shielded cable
Minimum Bend Radius: 60 mm (2.4 in)

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
