3300 NSv Extension Cable | Bently Nevada 330930-040-04-00

Description

330930-040-04-00 Model Number Breakdown

Base Model: 330930
Length Code: 040 → 4.0 m (13.1 ft)
Option Code: 04 → stainless steel armor, FEP jacket, connector protector
Approval Code: 00 → Not Required

Detailed Specifications

Cable Material: 75 Ω coaxial, FEP insulated
Armor: AISI 302 stainless steel sheath
Outer Diameter: 6.35 mm
Insulation Thickness: 0.7 mm
DC Resistance (center): 0.220 Ω/m (0.067 Ω/ft)
DC Resistance (shield): 0.066 Ω/m (0.020 Ω/ft)
Capacitance: 69.9 pF/m (21.3 pF/ft)
Max Current Rating: 1.0 A
Dielectric Strength: 2 000 V RMS
Weight per Meter: 0.37 kg
Tensile Strength: 220 N (50 lb)
Operating / Storage Temp: –51 °C to +177 °C
Altitude Rating: 0–3 000 m above sea level

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
