3300 XL 11 mm Probe | Bently Nevada | 330708-00-24-10-02-00

Description

Manufacturer: Bently Nevada

Model: 330708-00-24-10-02-00

Product Type: 3300 XL 11 mm Proximity Probe

Made In: USA

This probe features a 5/8-18 UNF thread with no armor. It comes with a Miniature coaxial ClickLoc connector and standard cable.

Dimensions & Length:

• Unthreaded Length: 0 in
• Case Length: 2.4 in
• Total Cable Length: 1.0 meter (3.3 feet)

Materials:

• Probe Tip: Polyphenylene sulfide (PPS)
• Probe Case: AISI 304 stainless steel (SST)
• Probe Cable: 75 Ω triaxial, FEP insulated

Operating Temperature:

• Range: -52°C to +177°C (-62°F to +351°F)
• Avoid below: -34°C (30°F) to protect pressure seal

Pressure Seal: Sealed with Viton O-ring. Not pressure-tested by default. Testing available on request.

Electrical Resistance:

• DC Resistance at 1.0 m: 5.9 ± 0.5 Ω

Thread and Torque Info:

• Thread Type: 5/8-18 UNF
• Max Thread Engagement: 0.938 in
• Max Torque: 45.2 N·m (400 in·lb)
• Recommended Torque: 15.2 N·m (133 in·lb)

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
