3300 XL 8 mm Probe – 330101-00-11-10-02-00 – Bently Nevada

Description

The 3300 XL 8 mm Probe (Model: 330101-00-11-10-02-00) by Bently Nevada delivers high-precision vibration and position monitoring for industrial machinery. Featuring a 3/8-24 UNF thread without armor, this probe is engineered for durability in harsh environments. The unthreaded length is 0.0 inches, with a compact case length of 1.1 inches and a total cable length of 1.0 meter. Equipped with a Miniature Coaxial ClickLoc connector, it ensures secure connections and reliable signal transmission.

Technical Specifications

• Temperature Range: -40°C to +120°C (-40°F to +248°F)
• Frequency Response: 0 Hz to 10 kHz (±3 dB)
• IP Rating: IP67 (dust/water resistant)
• Cable Jacket Material: PTFE (oil/chemical resistant)

Certifications & Compliance

• EMC Compatibility: Meets EN 61326-1 standards
• Hazardous Area Rating: Class I, Division 2 (optional)

The 330101-00-11-10-02-00 Probe combines rugged construction with ±5% linearity tolerance for critical machinery protection. Weight: 0.323 kg enables easy installation in tight spaces. 3-year warranty included.

Contact Inquiries: sales@nex-auto.com

Download PDF file here : 3300 XL 8 mm Proximity Transducer System Datasheet – 141194
