330701-00-24-90-12-00 | Bently Nevada Proximity Probes

Description

Bently Nevada 330701-00-24-90-12-00 3300 XL 11 mm Proximity Probe

Model: 330701-00-24-90-12-00

Made in: USA

Warranty: 12 months

Shipping Methods: FedEx, UPS, DHL

Quick Overview

Type: 3300 XL 11 mm Proximity Probe (no armor)

Thread: 1/2-20 UNF

Unthreaded Length: 00 = 0.0 in

Case Length: 24 = 2.4 in

Cable Length: 90 = 9.0 meters (29.5 ft)

Connector: 12 = ClickLoc, FluidLoc cable

Agency Approval: 00 = Not required

Material and Build

Tip: Polyphenylene sulfide (PPS)

Case: AISI 304 stainless steel

Cable Type: 75 Ω triaxial, FEP insulated

Minimum Bend Radius: 25.4 mm (1.0 in)

Temperature & Sealing

Working Range: -52°C to +177°C (-62°F to +351°F)

Seal Material: Viton O-ring (not pressure tested)

Electrical Specifications

Resistance (9.0 m cable): 8.5 ± 1.1 Ω

Installation Details

Thread Types: 1/2-20 UNF, M16x1.5

Max Thread Engagement: UNF: 0.750 in, M16: 24 mm

Max Case Torque: 45.2 N·m (400 in·lb)

Recommended Case Torque: 15.2 N·m (133 in·lb)

Max Connector Torque: 0.565 N·m (5 in·lb)

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
