330730-080-02-05 – Bently Nevada – Extension Cable

Description

Bently Nevada 330730-080-02-05 3300 XL 11 mm Extension Cable

Key Technical Specifications

• Cable Length: 8.0 meters (26.2 feet)
• Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Resistance (8.0 m):
  • Core: 2.0 ± 0.5 Ω
  • Jacket: 0.6 ± 0.2 Ω
• Cable Material: 75 Ω triaxial, FEP insulated
• Armor (Optional): Flexible stainless steel with FEP jacket
• Temperature Range: -52°C to +177°C (-62°F to +351°F)
• Weight: Standard: 45 g/m, Armored: 140 g/m

Installation & Wiring

• Field Wiring: 0.2 to 1.5 mm² (16 to 24 AWG)
• Recommended Cable: Shielded triad cable
• Max Length: 305 m (1000 ft) from sensor to monitor
• Connector: ClickLoc locking connectors
• Protection: Connector protectors stop moisture

Performance

• Linear Range: 0.5 mm to 4.5 mm (20 to 180 mils)
• DSL Range: 0.5 mm to 5.0 mm (20 to 200 mils)
• Recommended Gap: 2.5 mm (100 mils)
• Gold-Plated Connectors: Reduce signal loss

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
