3500/42-06-00 – Proximitor Seismic Monitor – Bently Nevada

Description

Proximitor Seismic Monitor by Bently Nevada

Experience the forefront of seismic monitoring technology with the 3500/42-06-00. This state-of-the-art Proximitor Seismic Monitor is engineered for unmatched precision in detecting and analyzing vibrations, making it a vital component for industrial safety and performance. Best suited for environments that demand rigorous monitoring, this device offers enhanced performance with its built-in internal barriers, ensuring secure operation in potentially hazardous areas.

System Overview

• Model: Bently Nevada 3500/42-06-00
• I/O Module Type: 06 – 135489-03 featuring internal barriers and terminations
• Channels: 4 Velomitor on channels 1 through 4 for comprehensive monitoring

Hazardous Area Approvals

Ensure compliance with safety standards through various approval options:

• 00 – None
• 01 – cNRTLus (Class 1, Division 2)
• 02 – ATEX / IECEx / CSA (Class 1, Zone 2)

Dimensions and Weight

• Height: 241.3 mm (9.50 in)
• Width: 24.4 mm (0.96 in)
• Depth: 241.8 mm (9.52 in)
• Weight: 0.91 kg (2.0 lb)

Advanced Frequency Response

• Bias: -3dB at 0.01 Hz for precise low-frequency tracking
• Velocity II Only: Not OK filter -3 dB at 40 Hz
• RMS Range: 10 to 5,500 Hz, -3 dB for flexible monitoring
• Peak Performance: 3 to 5,500 Hz, -3 dB for high accuracy

Contact Information

For more information or purchase inquiries, please reach us at sales@nex-auto.com

Download PDF file here:3500-42
