3704E Triconex – Tricon Analog Input Module
- Description
- Additional information
- Reviews (0)
- More Products
Description
Model 3704E
 Voltage Input Module
Key Highlights:
• Dual Voltage Range: 0-5V or 0-10V (±6% tolerance)
• 64-Channel Input with shared common terminal for simplified wiring
• High-Speed Operation: 75ms update rate across all channels
• Precision: 12-bit resolution (1 LSB = 0.024% FSR)
• Stability: <0.25% FSR accuracy over 0°C to 60°C
• Dual Voltage Range: 0-5V or 0-10V (±6% tolerance)
• 64-Channel Input with shared common terminal for simplified wiring
• High-Speed Operation: 75ms update rate across all channels
• Precision: 12-bit resolution (1 LSB = 0.024% FSR)
• Stability: <0.25% FSR accuracy over 0°C to 60°C
Enhanced Technical Specs:
• Input Impedance: 30 MΩ (DC) min | 30 kΩ when powered off
• Isolation Resistance: 200 kΩ leg-to-leg (typical)
• Noise Immunity: -12 dB @60Hz | -18 dB @120Hz
• Power Consumption: 2.8W typical at 24V DC
• Weight : 3.18 Kg
• Input Impedance: 30 MΩ (DC) min | 30 kΩ when powered off
• Isolation Resistance: 200 kΩ leg-to-leg (typical)
• Noise Immunity: -12 dB @60Hz | -18 dB @120Hz
• Power Consumption: 2.8W typical at 24V DC
• Weight : 3.18 Kg
Robust Design Features:
• Operating Range: -20°C to +70°C with 5-95% RH tolerance
• Shock & Vibration: 5g/10-500Hz operational resistance
• Connector Type: Removable screw terminal (16-pin)
• MTBF: 100,000 hours minimum at 25°C
• Certifications: CE, RoHS compliant | IP20 protection
• Operating Range: -20°C to +70°C with 5-95% RH tolerance
• Shock & Vibration: 5g/10-500Hz operational resistance
• Connector Type: Removable screw terminal (16-pin)
• MTBF: 100,000 hours minimum at 25°C
• Certifications: CE, RoHS compliant | IP20 protection
Contact sales@nex-auto.com
Additional information
| Weight | 3.18 kg |
|---|---|
| Dimensions | 24 × 24 × 3.5 cm |
