AC Drive | Allen-Bradley 25B-A2P5N114

Product Overview

The 25B-A2P5N114 is a PowerFlex 525 VFD by Allen-Bradley (Rockwell Automation).
It runs single-phase input and gives three-phase output.
Rated power: 0.5 HP (0.4 kW).

Key specs (short)

Input: 240 VAC, 1-phase.
Output: 0–240 VAC, 3-phase, 2.5 A.
Enclosure: IP20 / NEMA Open.
EMC: Built-in filter (EN61800-3).

Controls & I/O (brief)

Two analog inputs. Seven digital inputs (six programmable).
One analog output (10-bit). Two opto outputs. Two relay outputs.
Communications: Embedded Ethernet/IP and RS485/DSI.

New numeric details (added)

Based on Frame A dimensions (152 × 72 × 172 mm):

External volume (box approx): 1,882,368 mm³ (~1.882 L, ~114.9 in³).

External surface area (box approx): 98,944 mm² (~989.4 cm², ~153.4 in²).

UPC: 884951885646.

Warranty / shelf life: 1 year.
