Drive Overview

The 22B-V5P0H204 PowerFlex 40 drive from Allen-Bradley is a compact plate-mount adjustable frequency drive. It accepts single-phase input up to 120 VAC and delivers 5.0 A output for 1 HP motors via an intuitive keypad interface.

Performance Highlights

Input Voltage: 100–120 VAC, 50–60 Hz

Output Current: 5.0 A

Horsepower: 1 HP (0.75 kW)

Enclosure: Plate-mount, IP 20 front, NEMA/UL Open (no heatsink)

Control Modes: Sensorless Vector Control, Volts/Hz

Communication: RS-485

EMC Compliance: EN 50081-2 & EN 50082-2

Physical & Environmental

Dimensions: 125 × 204 × 97.5 mm (4.92 × 8.03 × 3.84 in)

Weight: 1.68 kg (3.7 lb)

Operating Temp: 0 °C to 60 °C (32–140 °F)

Storage Temp: –40 °C to 85 °C (–40–185 °F)

Humidity: 5 %–95 % RH (non-condensing)

Shock Resistance: 30 g, 11 ms pulses (operating); 50 g, 11 ms pulses (non-operating)

Vibration: 5 g, 10–500 Hz

Shelf Life: 1 year from manufacture
