Bently Nevada – 11 mm Proximity Probes – 330707-00-10-90-02-05

Model Breakdown

• 330707 – 11 mm probe, 5/8‑18 UNF thread, no armor
• 00 – Unthreaded length: 0 in
• 10 – Case length: 1.0 in
• 90 – Total cable length: 9.0 meters (29.5 feet)
• 02 – ClickLoc connector, standard cable
• 05 – Multiple approvals

Core Technical Data

• Probe tip material: Polyphenylene sulfide (PPS)
• Case material: AISI 304 stainless steel (SST)
• Cable type: 75 Ω triaxial, FEP insulated
• DC resistance at 9 m: 8.5 Ω ± 1.1
• Min bend radius: 25.4 mm (1.0 in)
• Temperature range: −52 °C to +177 °C (−62 °F to +351 °F)
• Shipping weight: 0.17 kg
• Humidity tolerance: 0–95% non-condensing
