Bently Nevada 190501-12-99-00 – 100% Original Brand New Transducer

Description

Bently Nevada Velomitor CT Velocity Transducer – Model 190501-12-99-00

Key Technical Specifications

• Measurement Range: 0.229 mm/s (0.009 in/s) pk broadband
• Amplitude Linearity: ±2% to 63.5 mm/s pk (2.5 in/s pk)
• Sensitivity: 3.94 mV/mm/s (100 mV/in/s) ±5%
• Frequency Response: 3.0 Hz to 900 Hz (180 to 54,000 cpm) ±1.0 dB, 1.5 Hz to 1.0 kHz (90 to 60,000 cpm) ±3.0 dB
• Output Bias Voltage: 10.1 Vdc ± 1.0 Vdc, Pin A referenced to Pin B
• Dynamic Output Impedance: <400 Ω typical
• Operating Temperature: -40°C to +85°C (-40°F to +185°F)
• Storage Temperature: -40°C to +100°C (-40°F to +212°F)
• Shock Limit: 5000 g pk, maximum
• Humidity Limit: 100% condensing, non-submerged
• Magnetic Field Susceptibility: <0.0068 mm/s/gauss (0.268 mil/s/gauss) @ 50 gauss, 50-60Hz

Installation Guidelines

• Mounting Torque: 4.5 N-m ± 0.6 N-m (40 in–lbf ± 5 in-lbf)
• Mounting Surface Diameter: 33 mm (1.3 in)
• Height: 82 mm (3.2 in)
• Mounting Angle: Any orientation
• Polarity: Pin A goes positive with respect to Pin B when velocity is from base to top

Download PDF file here:190501-Datasheet
