Bently Nevada | 3300 5mm Probe | 330172-12-23-10-01-05

Description

Mid-Length 5 mm Proximity Probe – Model 330172‑12‑23‑10‑01‑05

The 330172‑12‑23‑10‑01‑05 proximity probe from Bently Nevada is designed for medium-depth installations requiring enhanced durability. It features a 2.3 in stainless steel case, 1.2 in unthreaded section, and a connector protector for rugged environments. Built for high reliability with multiple global approvals and a one-year warranty.

Model Breakdown

Main Model: 330172
Suffix Details:
–12 = Unthreaded Length: 1.2 in
–23 = Case Length: 2.3 in
–10 = Cable Length: 1.0 m (3.3 ft)
–01 = ClickLoc Coax Connector with Protector
–05 = Multiple Agency Approvals

Performance Specifications

• Operating Voltage: –17.5 V to –26 V, max 12 mA
• Typical Gap Measurement: 1.27 mm (50 mils)
• Output Resistance: 50 Ω
• DC Resistance: 7.59 Ω ± 0.50 (center to outer conductor)
• Signal Linearity Error: ±0.5 % of full scale
• Response Time: <0.1 ms
• Dielectric Strength: 500 V RMS, 60 s
• EMC Immunity: ≥20 V/m up to 1 GHz
• Shelf Life: 1 year

Download PDF file here:3300 5 mm Transducer System Datasheet – 172036
