Bently Nevada – 3300 NSv Probe 330901-10-40-10-02-00

3300 NSv Proximity Probe Overview

The 330901‑10‑40‑10‑02‑00 probe measures shaft vibration.
It has a 1 in tip, a
4 in body, and a
1 m cable with a ClickLoc connector.

Key Specs

• Model Parts:
  • 330901 – Base
  • 10 (1 in tip)
  • 40 (4 in body)
  • 10 (1 m cable)
  • 02 (ClickLoc cable)
• Case: Stainless steel
• Tip: PPS plastic
• Cable: 75 Ω coaxial, FEP jacket
• Resistance: 4.2 ± 0.5 Ω at 1 m
• Max Torque: 7.3 N·m
  Use Torque: 5.1 N·m
• Temp Range: –52 °C to +177 °C
• Weight: 18 g per 10 cm cable
• Response: 1 µs
• Sensitivity: ± 10 µm
• MTBF: 100 000 hours
• Warranty: 1 year

Applications

Use this probe on rotating machines.
It works up to 20 000 RPM.
Noise is under 0.5 µm.
It seals up to 5 bar.
