Bently Nevada 330701-00-24-10-12-00 – New 11mm Proximity Probe

Description

Bently Nevada 330701-00-24-10-12-00 3300 XL 11 mm Proximity Probe

Model: 330701-00-24-10-12-00

Made in: USA

Warranty: 12 months

Shipping: FedEx, UPS, DHL

Main Details

Thread Size: 1/2-20 UNF

Unthreaded Part: 00 = 0 inch

Case Length: 24 = 2.4 inch

Cable Length: 10 = 1.0 meter (3.3 ft)

Connector: 12 = ClickLoc with FluidLoc cable

Build and Materials

Tip: Polyphenylene sulfide (PPS)

Case: AISI 304 stainless steel

Cable: 75 Ω triaxial, FEP insulated

Temp Range: -52°C to +177°C (-62°F to +351°F)

Seal Type: Viton O-ring

Bend Radius: 25.4 mm (1 inch)

Install Info

Case Thread: 1/2-20 UNF and M16x1.5

Max Thread Depth (1/2-20): 0.75 inch

Max Thread Depth (M16): 24 mm

Max Torque: 45.2 N·m (400 in·lb)

Best Torque: 15.2 N·m (133 in·lb)

Connector Torque: Max 0.565 N·m (5 in·lb)

Best Connector Fit: Finger tight

Electrical Data

Probe Resistance (1 m): 5.9 ± 0.5 Ω

Model Breakdown

330701 = XL 11 mm probe type

00 = No unthreaded section

24 = 2.4 in case length

10 = 1.0 m cable

12 = ClickLoc + FluidLoc cable

00 = No approval needed

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
