Bently Nevada 330707-00-10-50-12-05 – New Proximity Probes

330707-00-10-50-12-05 Model & Option Breakdown

330707 – 11 mm probe tip;
00 – 0 in unthreaded length;
10 – 1.0 in overall case length;
50 – 5.0 m total length;
12 – Miniature ClickLoc connector;
05 – Multiple agency approvals.

Key Specifications

Tip material: Polyphenylene sulfide (PPS)

Case material: AISI 304 SST

Probe cable: 75 Ω triaxial FEP, Ø 4.5 mm, capacitance 35 pF/m, inductance 500 nH/m

Temperature range: –51 °C to +177 °C (–60 °F to +351 °F)

Pressure seal: Viton® O‑ring (not factory tested; custom testing available)

Bend radius: 25.4 mm (1.0 in)

Thread engagement: 0.750 in max; torque rated 45.2 N·m, recommended 15.2 N·m

Connector cycles: ≥ 500 mating operations

Shipping weight: 0.17 kg; package length: 200 mm
