Description

Manufacturer: Bently Nevada

Product No.: 330707-00-26-10-11-05

Product Type: 3300 XL 11 mm Proximity Probe

Origin: Made in U.S.A (COO available)

Model Details:

  • 330707: 11 mm probe, 5/8-18 UNF thread, no armor
  • 00: No unthreaded length
  • 26: Case length 2.6 in
  • 10: Cable length 1.0 m (3.3 ft)
  • 11: Mini ClickLoc connector with protector, FluidLoc cable
  • 05: Approved for use in multiple regions

Key Features:

  • Tip Material: Polyphenylene sulfide (PPS)
  • Case Material: AISI 304 stainless steel
  • Cable Type: 75 Ω triaxial, FEP insulated
  • Available Cable Lengths: 1, 5, or 9 meters
  • Operating Temp: -52°C to +177°C (−62°F to +351°F)
  • Minimum Bend Radius: 25.4 mm (1.0 in)
  • Shipping Weight: 0.17 kg

Mechanical Details:

  • Thread Size: 5/8-18 UNF
  • Max Thread Engagement: 0.938 in
  • Max Torque: 45.2 N·m (400 in·lb)
  • Recommended Torque: 15.2 N·m (133 in·lb)
  • Connector Torque: Finger-tight; Max 0.565 N·m (5 in·lb)

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet

Additional information

Weight0.17 kg
Dimensions24 × 3 × 24 cm
