Bently Nevada 330708-00-24-10-01-05 | 11 mm Armored Probe

Description

Manufacturer: Bently Nevada
Product Number: 330708-00-24-10-01-05
Product Type: 3300 XL 11 mm Proximity Probe
Made in U.S.A | COO available

Model Features
– Thread: 5/8-18 UNF, no armor
– Unthreaded Length: 0 in
– Case Length: 2.4 in
– Cable Length: 1.0 meter (3.3 ft)
– Connector: Mini coaxial ClickLoc with protector
– Agency Approvals: Multiple (Option 05)

Materials
– Tip: Polyphenylene sulfide (PPS)
– Case: AISI 304 Stainless Steel
– Cable: 75 Ω triaxial, FEP insulated, available in 1, 5, or 9 meters
– Min Bend Radius: 25.4 mm (1.0 in)

Technical Specs
– Temp Range: -51°C to +177°C (-60°F to +351°F)
– DC Resistance (1m cable): 5.9 ± 0.5 Ω
– Max Thread Engagement (5/8-18): 0.938 in
– Probe Case Torque:
Recommended: 15.2 N·m (133 in·lb)
Max Rated: 45.2 N·m (400 in·lb)
– Connector Torque:
Recommended: Finger tight
Max: 0.565 N·m (5 in·lb)

Other Threads
– M16x1.5 Max Engagement: 24 mm
– M14x1.5 Max Engagement: 21 mm

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
