Bently Nevada 330905-00-05-05-02-05 – 3300 NSv Proximity Probes

Description

Bently Nevada 330905-00-05-05-02-05 | 3300 NSv Proximity Probe

Suffix Breakdown

Model: 330905

Unthreaded Length: 00 mm

Case Length: 50 mm

Cable Length: 0.5 meter

Connector: Miniature coaxial ClickLoc

Approvals: Multiple Approvals (Code 05)

Technical Specifications

Brand: Bently Nevada

Model: 330905-00-05-05-02-05

Measuring Range: 1.5 mm (60 mils)

Recommended Gap: 1.0 mm (40 mils)

Accuracy: ±0.06 mm (±2.3 mils)

Output Signal: -1 to -13 Vdc

Incremental Scale Factor: 7.87 V/mm (200 mV/mil)

Frequency Response: 0 to 10 kHz

Operating Temp: -52°C to +177°C (-62°F to +351°F)

Cable Type: 75 Ω coaxial FEP-insulated

Cable Resistance: 0.220 Ω/m (center), 0.066 Ω/m (shield)

Capacitance: 69.9 pF/m

Installation Guide

Threaded Mount: M10x1

Torque: Max 0.56 N•m (5 in•lb), finger-tight recommended

Min Bend Radius: 25.4 mm (1.0 in)

Field Wiring: Use 3-conductor shielded triad cable, 16–24 AWG
