Bently Nevada 330909-00-28-70-01-00 | Armored Probes

330909‑00‑28‑70‑01‑00 NSv Proximity Probe Overview

Detailed Suffix Explanation

00 = 0.0 in unthreaded probe section

28 = Overall case length: 2.8 in

70 = Total cable length: 7.0 m (23.0 ft)

01 = Miniature coaxial ClickLoc connector with protector

00 = No agency approvals required

Technical Performance Data

Case Material: AISI 304 stainless steel

Tip Composition: PPS (Polyphenylene sulfide)

Cable Type: 75 Ω coaxial, FEP-insulated

DC Resistance at 7.0 m: 5.9 Ω ± 0.9 Ω

Weight: 14 to 150 g (0.5 to 5.3 oz)

Operating Temperature Range: –52 °C to +177 °C

Storage Temperature Range: –52 °C to +177 °C

Thread Engagement Limit: 0.563 in max

Max Connector Torque: 33.9 N·m

Recommended Connector Torque: 11.3 N·m

First 3 Thread Torque Max: 22.6 N·m

Pressure Seal: Viton O-ring for differential protection

Ingress Protection: IP66 rating (new)

Electrical Isolation: 1500 V RMS dielectric strength (new)

Accuracy: ± 2% of full scale (new)

Shock Tolerance: 100 g, 11 ms duration (new)

Expected Shelf Life: 1 year
