Bently Nevada 3300 NSv Proximity Probe

Model: 330910-07-23-50-02-00

This probe fits small machines. It reads shaft position and vibration in harsh places.

Product Details:

Base Model: 330905 with M10X1 thread and steel armor.

Unthreaded Length: 70 mm. Must be 20 mm shorter than case.

Case Length: 230 mm.

Cable Length: 5.0 meters (16.4 feet).

Connector: ClickLoc small connector with standard cable.

Approval: -00 not required.

Electrical Data:

DC Resistance: 5.3 ± 0.7 Ω at 5.0 m.

Cable: 75 Ω coaxial, FEP-insulated.

Mechanical Info:

Tip: PPS plastic.

Case: AISI 304 steel.

Min Bend Radius: 25.4 mm (1.0 in).

Weight: 14–150 g (0.5–5.3 oz).

Thread: M10X1, max depth 15 mm.

Torque:

Case max: 33.9 N·m (300 in·lb).

Case recommended: 11.3 N·m (100 in·lb).

Connector max: 0.56 N·m (5 in·lb).

Temperature:

Working: -52°C to +177°C (-62°F to +351°F).

Storage: -52°C to +177°C.

Note: Below -34°C may harm seal.

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385

Additional information

Weight0.15 kg
Dimensions24 × 24 × 3 cm
