Bently Nevada New Dual NSv Probe | 330908-12-46-10-02-00

Description

330908-12-46-10-02-00 3300 NSv Proximity Probes

This probe checks machine parts without touching them. Good for factories and tough places. Here’s what you need to know:

Model Numbers

Full Model: 330908-12-46-10-02-00

Base: 330908 (3/8-24 UNF thread, no armor)
Unthreaded length: 12 (1.2 inches)
Case length: 46 (4.6 inches)
Total length: 10 (1.0 meter / 39 inches)
Connector: 02 (small coaxial ClickLoc, standard cable)
Approvals: 00 (no extra tests needed)

What It’s Made Of

Case: AISI304 Stainless Steel (stops rust, lasts long)
Tip: Polyphenylene Sulfide (PPS) (takes high heat, smooth surface)
Cable: 75Ω coaxial with FEP coating. Comes in 0.5m, 1m, 5m, 7m. Keeps signals clear.

How It Works

DC Resistance (1.0m): 4.2 ± 0.5 ohms (from center to outer wire)
Torque limits:

Max for connectors: 33.9 N·m (300 in·lbs)
Best to use: 11.3 N·m (100 in·lbs)
Thread fit (3/8-24): 0.563 inches (stays tight when put in)
Works up to 8kHz (good for fast checks)
Cable pull: 330N (75 lbs) (stays connected when pulled)

Where It Works

Works and stores from -52°C to +177°C (-62°F to +351°F). Staying below -34°C (-30°F) for long may break the seal (Viton O-ring). Seals pressure but not tested before shipping. Weighs 14-150g (0.5-5.3 oz) (light and easy to install).

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
