DC Voltage Output Module IC694MDL758 GE Fanuc Emerson

Description

GE Fanuc IC694MDL758 Discrete Output Module

Technical Parameters

• Operating voltage: 12 to 24 V DC
• Output current per point: 0.5 A
• Aggregate group current: 8 A
• Isolation voltage: 1500 Vrms
• Accuracy: ± 0.5 %
• Response time: 0.5 ms
• Output type: Positive logic (source)
• Operating temperature: – 20 to + 60 °C
• Backplane draw: 250 mA @ 5 V
• Inrush current: 5.4 A for 10 ms

Model Code Breakdown

• IC694MDL758
  • IC694 – RX3i platform
  • MDL – Discrete I/O module
  • 758 – 32 outputs, 2 x 16 groups
