GE Fanuc Emerson IC693MDL241 Series 90-30 Module

Description

GE Fanuc IC693MDL241 Series 90-30 24V AC/DC 16-Channel Discrete Input Module

Technical Specifications

Brand: GE Intelligent Platforms / GE Fanuc

Series: Series 90-30

Part Number: IC693MDL241

Product Type: Discrete Input Module

Input Channels: 16

Input Voltage Range: 0-30 V AC/DC

Nominal Voltage: 24 V AC/DC

Input Current at Rated Voltage: 7 mA

On-State Voltage: 11.5-30 V AC/DC

Off-State Voltage: 0-4 V AC/DC

On-State Current: 3.2 mA

Off-State Current: 1 mA

Typical On Response Time: 12 ms

Maximum Off Response Time: 28 ms

Isolation: 1500 V RMS (field vs logic side)

AC Power: Yes | DC Power: Yes

LED Indicators: 16 (green for ON/OFF)

Logic Reading: %I
