GE Fanuc IC200BEM103 Interface Module

Description

GE Fanuc IC200BEM103 Versamax Network Interface Module

Product Overview

The IC200BEM103 is a network interface module from GE Fanuc.

It supports up to 40 slave devices.

It exchanges up to 512 bytes input and output data.

Technical Specifications

• Part Number: IC200BEM103
• Brand: GE Fanuc
• Series: Versamax
• Description: Network interface module
• Slave Devices: 40
• Data Rate: 125 / 250 / 500 Kbaud
• Data Exchange: 512 bytes input · 512 bytes output
• Data Size: 0–8 bytes
• Module Support: 64 nodes without bridging
• Connector: 5-pin open connector
• Power Consumption: 140 mA from 5 V bus
• DeviceNet Max: 125 mA
• Temperature: 0–60 °C
• Cable: Shielded pair with 19-strand drain wire
• Enclosure Rating: Class I Division 2
