GE Fanuc IC693MAR590 I/O Module

Description

GE Fanuc IC693MAR590 Input/Relay Output Module – Series 90-30

Technical Specifications

• Brand: GE Fanuc
• Series: Series 90-30
• Part Number: IC693MAR590
• Channels: 8 Inputs / 8 Outputs
• Rated Input Voltage: 0 to 132 Volts AC
• Rated Output Voltage: 5 to 30 Volts DC / 5 to 250 Volts AC
• Isolation Voltage: 1500 Volts RMS (Field to Logic Side)
• Maximum Output Load: 2 Amps
• Maximum Inrush: 5 Amps
• Response Time: 15 milliseconds
• Power Consumption: 80 mA from 5 Volts DC / 70 mA from 24 Volts DC relay
• ON-State Voltage: 74 to 132 Volts AC
• OFF-State Voltage: 0 to 20 Volts AC
• ON-State Current: 6 mA
• OFF-State Current: 2.2 mA for 30 milliseconds

Features

• Provides 8 input and 8 output points.
• Works with GE Series 90-30 PLCs.
• Isolation voltage of 1500 Volts RMS.
• Supports both 5-slot and 10-slot baseplates.
• Fast response time of 15 milliseconds.
• High-voltage protection with a card for data recording.
• Can control switches, buttons, and limit switches.
