GE Fanuc IC694APU305 I/O Processing Module

Description

GE Fanuc IC694APU305 RX3i Pulse I/O Module — High-Speed Counter

Key Benefits

Processes pulse trains quickly for precise industrial measurement.

Provides field I/O power for most pulse devices on the inputs.

Optically isolated I/O reduces risk from surges and ground loops.

Scales easily — add modules without system slot limits.

Supports both absolute and quadrature encoder counting modes.

Technical Specifications

Brand: GE Fanuc

Series: RX3i PacSystem

Model: IC694APU305

Backplane Supply: 5V DC

Power Current: 360 mA plus 10 mA per faceplate output

Field-to-Logic Isolation: Peak 1500V for one second

Steady State Isolation: 30 V AC / V DC

Input Type: Positive logic, optically isolated

Output Type: Positive logic, optically isolated

Maximum Supply Voltage for I/O: 30V DC

Output Fuse: 5 A replaceable, common to all outputs

Typical Input Impedance: 4300 Ohms

Hysteresis: 250 mV

Max Count Rate: 30 kHz with absolute encoder

Max Count Rate: 200 kHz with Quad B encoder

Recommended Wiring: Shielded cable with maximum length of 30 meters

Module Capacity: No practical limit to number per RX3i system
