GE Fanuc IC694DNM200 RX3i DeviceNet Master Module
Product Overview
The IC694DNM200 is a DeviceNet Master module for RX3i PLCs.
It supports up to 63 DeviceNet slaves.
The module allows 255 Bytes of input and output per slave device.
It includes one RS232 service port and one DeviceNet port.
Install the module in any available slot of the RX3i or Series 90-30 backplane.
Use this module to implement distributed I/O architectures and network control.
Communication rates: 125k, 250k, 500k baud.
The module draws 450 mA at 5 V DC from the backplane.
Hot swapping is not supported.
Technical Specifications
Manufacturer: Emerson Automation
Series: PACSystem RX3i
Part Number: IC694DNM200
Product Type: DeviceNet Master Module
Protocol: DeviceNet
Compatible CPUs: Version 3.5 or later
Mounting location: RX3i or Series 90-30 backplane
Power consumption: 450 mA @ 5 V DC
DeviceNet Communication Details
| Feature | Specification |
|---|---|
| Maximum Slaves | 63 |
| Input per Slave | 255 Bytes |
| Output per Slave | 255 Bytes |
| Total I/O | 3972 Bytes |
| Baud Rates | 125k, 250k, 500k |
Additional information
| Weight | 0.5 kg |
|---|---|
| Dimensions | 13 × 12 × 3 cm |
