I/O Terminals GE Fanuc IC200CHS015

Description

GE Fanuc Versamax IC200CHS015 Spring-Style I/O Terminal

Technical Specifications

• Brand: GE Fanuc
• Series: Versamax
• Part Number: IC200CHS015
• Type: Spring-style interposing I/O terminal
• Clamps: 36 spring-style
• Dimensions: 105.44 x 110.5 mm
• Depth: 70 mm
• Single Wire: 22 to 14 AWG
• Two Wires: up to 18 AWG
• Cable Type: Solid or stranded copper
• Vertical Spacing: 2 inches
• Horizontal Spacing: 1 inch
• Mounting: DIN rail, grounded
• Operating Temp: -40 to 60 °C
• Storage Temp: -40 to 85 °C
• Vibration Rating: 1 G at 57-150 Hz, 0.012 in peak-to-peak at 10-57 Hz

Key Benefits

• 36 spring clamps ensure fast and secure wiring.
• Hinged door protects terminals and allows labels.
• Supports quick module replacement to reduce downtime.
• Durable for harsh industrial conditions.
• Clearances allow proper air flow and cooling.
