IC693CHS393 – GE Fanuc – Expansion Baseplate

Description

IC693CHS393 GE Fanuc Series 90-30 Remote I/O Baseplate

Product Overview

The IC693CHS393 is a 10-slot remote I/O baseplate for GE Fanuc Series 90-30 systems. It lets you place I/O modules far from the CPU, up to 700 feet away. This obsolete part is available from our stock.

Key Technical Specifications

Slots: 10 slots for I/O modules.

Voltage: 5V DC.

Current Load: 460 mA.

Max Distance: 700 feet from CPU.

Expansion Connector: 25-pin female.

Weight: 3.1 kg.

Dimensions: 443mm L x 130mm W x 142mm H.

Operating Temperature: 0 to 60 °C.

Installation Guide

Mount the baseplate on a panel. Ensure the main power is off before starting. Connect the power supply to the dedicated slot. Use a serial cable to link back to the CPU baseplate. The total cable length for all remote bases must not exceed 700 feet. Keep the unit dry and clean.

Compatibility Notes

Works with Series 90-30 PLCs. Supports up to 4 remote bases with CPUs 331, 340, 341. Supports up to 7 remote bases with CPU 350 or higher. Does not support intelligent modules like PCM, ADC, or CMM. Use a DIP switch to set the rack address.

Industrial Applications & Solutions

Perfect for large factory floors. Places I/O close to sensors on big machines. Solves long-distance wiring problems. Reduces signal noise in automotive plants. Ideal for water treatment plant controls. Great for distributed conveyor systems. Lowers installation costs by simplifying wiring.

Packaging List

You get one IC693CHS393 remote baseplate. No cables or power supply are included.

Shipping & Support

We ship globally via FedEx, UPS, and DHL. This product has a 12-month warranty. Our team offers 24/7 technical support for setup and troubleshooting.
