Input Module – GE Fanuc IC200ALG266

Description

GE Fanuc IC200ALG266 VersaMax 15-Point Analog Input Module

Technical Specifications

• Brand: GE Fanuc
• Series: VersaMax
• Part Number: IC200ALG266
• Type: Analog Input Module
• Channels: 15 single-ended
• Input Range: -10 VDC to +10 VDC
• Resolution: 15-bit, 0.3125 mV per count
• Update Time: 7.5 ms
• Input Impedance: 100 kΩ
• Filter: 32 Hz ±20%
• Isolation: 250 VAC continuous, 1500 VAC for 1 min
• Accuracy: ±0.3% typical, ±1% max
• Diagnostics: Power loss, A/D error
• Indicator: OK LED
• Backplane Load: 150 mA max at 5 VDC
• Module Size: Single slot
• Wiring: Single-ended, one group

Main Benefits

• Accurate data with 15-bit resolution.
• Fast 7.5 ms updates for real-time use.
• Built-in fault checks improve safety.
• Protection from surges above 30 VDC.
• Easy install with no extra power supply.
