Description
GE Fanuc IC200MDL643 Versamax Discrete Input Module
Key Features
Flexible Logic Configuration: Each group supports positive or negative logic independently for maximum flexibility.
LED Indicators: Individual LED per input and one “OK” LED for overall status.
TTL Compatible: Negative logic inputs work with TTL devices.
Fast Response: Maximum on/off response time 0.25 milliseconds.
Input Filtering: Configurable at 0.25 ms, 1.25 ms, or 7.25 ms to reduce noise and switch bounce.
Technical Specifications
| Brand | GE Fanuc |
| Series | Versamax |
| Model | IC200MDL643 |
| Module ID | FFFF8008 |
| Number of Input Points | 16 |
| Number of Groups | 2 |
| Input Voltage | 0–15 V DC, nominal 5/12 V DC |
| Input Impedance | 2.4K Ohms |
| Group-to-Group Isolation | 250 VAC continuous, 1500 VAC for 1 min |
| Point-to-Point Isolation | None |
| LED Indicators | One per point, plus one “OK” LED |
| Backplane Current Consumption | 5 V, 70 mA |
| Minimum On-State Current | 1.45 mA |
| Minimum Off-State Current | 0–0.7 mA |
| Max On/Off Response Time | 0.25 ms |
| Configurable Input Filter Times | 0.25 ms, 1.25 ms, 7.25 ms |
| Shorting Bar Capacity | 2 Amps for B Terminal |
| External Power Supply | Not required |
| Thermal Derating | None |
FAQ
Q: Is the IC200MDL643 full new and original?
A: Yes, the IC200MDL643 is brand new and original.
Q: Do you have it in stock?
A: Yes, we maintain inventory and ship within 5 days.
Q: What shipping methods are available?
A: Common logistics include DHL, FedEx, and UPS.
Q: What is the input voltage range for the IC200MDL643?
A: It supports 0–15 V DC with nominal 5/12 V DC operation.
Q: How fast is the response time?
A: Maximum on/off response time is 0.25 milliseconds for precise input detection.
Q: Are positive and negative logic configurations supported?
A: Yes, each group can independently operate in positive or negative logic.
Additional information
| Weight | 0.5 kg |
|---|---|
| Dimensions | 15 × 15 × 8 cm |
