New 11 mm Probe | Bently Nevada 330707-00-15-10-02-05

Description

Product Snapshot

Brand: Bently Nevada
Model: 330707‑00‑15‑10‑02‑05
Type: 3300 XL 11 mm Proximity Probe

Dimensions & Thread

Case Length: 1.5 in
Total Length: 1.0 m (3.3 ft)
Thread: 5/8‑18 UNF, no armor

Connector & Cable

Connector: ClickLoc miniature coaxial (standard cable)
Cable: 75 Ω triaxial, FEP insulated
Lengths: 1 m, 5 m, 9 m

Materials

Tip: Polyphenylene sulfide (PPS)
Case: AISI 304 stainless steel

Environmental Specs

Temperature: –51 °C to +177 °C
Bend Radius: 25.4 mm (1 in)

Seal & Torque

Seal: Viton O‑ring (custom test on request)
Max Engagement: 0.938 in
Max Torque: 45.2 N·m
Recommended Torque: 15.2 N·m

Performance & Weight

Resistance @1 m: 5.9 ± 0.5 Ω
Shipping Weight: 0.17 kg

Highlights

• Easy installation, rugged design
• Accurate readings in harsh environments
• 1 Year warranty included

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
