Reverse Mount Probe Bently Nevada | 330907-05-30-50-12-00

Description

Overview

The 330907-05-30-50-12-00 is a 3300 NSv reverse mount probe by Bently Nevada. Made in the USA, it works in tough compressor settings.

Model Details

Threads (05‑30): M10×1

Length (50): 5.0 m (16.4 ft)

Connector (12): Mini coaxial ClickLoc, FluidLoc cable

Agency (00): No approval needed

Key Benefits

Stronger chemical resistance than 3300 RAM probe

Clear side‑view signal over 3000 190 probe

Gold‑plated ClickLoc connectors lock firmly

TipLoc molding bonds tip and body

Technical Specs

DC Resistance: 5.3 ± 0.7 Ω @ 5 m

Wiring: 0.2–1.5 mm² (16–24 AWG), shielded triad, max 305 m

Linear Range: 0.25–1.75 mm (10–70 mils); use 1.0 mm gap

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
